Roberts 10-91 - Page 6

- 5 -
ROBERTS 10-91 PARTS LIST
NO. DESCRIPTION QTY. NO. DESCRIPTION QTY.
1 Screw M6 × 12 4 25 Right ABS Handle 1
2 Washer Φ6 2 26 Bolt M4 × 30 2
3 Rubber Feet 6 27 Left ABS Handle 2
4 Rod 4 28 Guide Bar 1
5 Hex Bolt M8 × 55 1 29 Screw M5 × 8 8
6 Hex Bolt M8 × 50 1 30 Nut M10 4
7 Main Base 2 31 Sleeve 6
8 Screw M4 × 14 2 32 Nut M5 3
9 Nylon Bar 2 33 Working Table 3
10 Blade 2 34 Screw M5 ×12 3
11 Spring 2 35 Carry Handle 3
12 Screw M5 × 10 1 36 End Board 1
13 Blade Base 2 37 Foot 1
14 Screw M8 × 14 1 38 Bolt M8 × 30 4
15 Nut M12 1 39 Frame A 1
16 Nylon Wheel 2 40 Cross Bar 3
17 Aluminum Eccentric Cam 1 41 Frame B 1
18 Screw M6 × 16 1 42 Spring Pin 1
19 Handle Base 1 43 Nut M8 4
20 Bolt M12 × 120 2 44 Pin Sleeve 2
21 Handle A 1 45 Screw M4 × 10 4
22 Screw M8 2 46 Pin 2
23 Handle B 1 47 Shaft 2
24 Nut M4 1
