ROBERTS 10-94 PARTS LIST
NO. DESCRIPTION QTY. NO. DESCRIPTION QTY.
1 Screw M6 × 12 4 25 Right ABS Handle 1
2 Washer Φ6 4 26 Bolt M4 × 30 2
3 Rubber Feet 4 27 Left ABS Handle 2
4 Rod 2 28 Guide Bar 1
5 Hex Bolt M8 × 55 4 29 Screw M5 × 8 9
6 Hex Bolt M8 × 50 4 30 Nut M10 4
7 Main Base 1 31 Sleeve 6
8 Screw M4 × 14 5 32 Nut M5 3
9 Nylon Bar 1 33 Working Table 3
10 Blade 1 34 Screw M5 ×12 3
11 Spring 1 35 Carry Handle 3
12 Screw M5 × 10 5 36 End Board 1
13 Blade Base 1 37 Foot 1
14 Screw M8 × 14 2 38 Bolt M8 × 30 4
15 Shaft 2 39 Frame A 1
16 Nut M12 1 40 Cross Bar 3
17 Nylon Wheel 2 41 Frame B 1
18 Aluminum Eccentric Cam 1 42 Sping Pin 1
19 Handle Base 1 43 Nut M8 4
20 Bolt M12 × 120 1 44 Pin Sleeve 2
21 Handle A 1 45 Screw M4 × 10 4
22 Screw M8 2 46 Pin 2
23 Handle B 1 47 Screw M6 × 16 4
24 Nut M4 2
