Specifications
Power Requirements
Mains : 220/240volts, 50/60Hz only
Batteries : 6.0V 4 x IEC R14 (C size) cells
Battery Life
Approx. 50hrs of listening for 4 hours a day at
normal volume, using Alkaline cells.
Note: FM Preset stations will not remain in tune
when the battery falls below 4.0V.
Frequency Coverage
FM 87.5-108MHz
MW 525 - 1605kHz
LW 147 - 284kHz
Circuit Features
3 IC's, 10 Transistors, 21 Diodes, 3 Varicap diodes, 3 Zener diode3, 5 LED's.
Loudspeaker 100mm 4ohms
Output Power 1watt into 4ohms
Headphone socket 3.5mm dia
Aerial System FM Telescopic aerial
MW Built-in Ferrite aerial
LW Built-in Ferrite aerial
The Company reserves the right to amend the specification without notice.
