Controls and connections - cont.
Rear view
18. Headphone socket
19. Line output socket
20. Auxiliary input socket
21. USB playback socket
22. Ethernet socket (RJ-45)
23. DC input socket
24. Subwoofer
25. Telescopic aerial (antenna cable socket behind)
20 19 18
25
24
1
2
3
4
5
8
7
9
12
Remote control
handset
1. On / Standby / Sleep button
2. Preset buttons 1-5 / Playback
control buttons
3. Mode button
4. Info / Brightness button
9ROXPH'RZQEXWWRQ
9ROXPH8SEXWWRQ
7. Select / Snooze button
8. Tuning / Menu Up button
9. Menu Back button
10.Tuning / Menu Down button
11.Alarm button
3UHVHW5HSHDW6KXIÀHEXWWRQ
13.Menu Forward button
14.Menu button
