Robin 109 - Preparations for Storage; Water Drainage; Disconnect Delivery Hose; Discharge Fuel

10
GB
8. FUEL HOSE REPLACEMENT
(See Fig.
77
77
7
-
!1!1
!1!1
!1,
!2!2
!2!2
!2)
9. CHECKING BOLTS, NUTS AND SCREWS
■ Retighten loose bolts and nuts.
■ Check for fuel and oil leaks.
■ Replace damaged parts with new ones.
10. CLEANING PUMP INSIDE
■ Turn the knob counterclockwise and open the casing
cover holder.
■Pull the casing toward you, and then remove the casing
and the inner casing.
■ Clean the inside of pump casing and casing cover with
clean water.
Replace the fuel hose every 2 years. If fuel leaks from fuel
hose, replace the fuel hose immediately.
1. FUNCTION OF OIL SENSOR
The engine will stop automatically when the oil level falls
below the safety limit. The engine cannot be started unless
the level is raised above the prescribed limit.
(See Fig.8
- e)
2. RESTARTING
(1) Fill the crankcase with oil up to the proper level.
(2) As for restarting and operating the engine, refer to
section “4. OPERATING YOUR PUMP” on page 7.
■ Check the wire connector from the engine. It must be
connected securely to the wire from oil sensor.
(See Fig.8
- r - w Fix the earth wire.)
■ Do not remove the oil sensor from the engine for
checking oil level and refilling. (See Fig.8
- r - q)
■ When selecting the engine oil, refer to page 6 for the
recommended oil.
7. OIL SENSOR INSTRUCTIONS
(Except PTG109)
(OPTIONAL)
1. WATER (Except PTG208D,307D)
(See Fig.
88
88
8
-
qq
qq
q,
ww
ww
w)
Drain all water from the drain plug.
6. PREPARATIONS FOR STORAGE
If you do not use the engine more than 1 month, discharge
fuel to prevent gum in the fuel system and carburetor parts.
■

Remove the strainer cup, place the strainer over a
container and open the strainer cock to discharge fuel
from the fuel tank.
■

Remove the drain screw of the carburetor float chamber
and discharge fuel.
When retightening drain plug, be sure to clean
the drain plug and the thread of casing. Otherwise,
the thread may be damaged.
CAUTION
2. DISCONNECT THE DELIVERY HOSE
(PTG208D, 307D)
Tilt the pump and drain all water from delivery hole. Severe
damage to pump may result if water freezes in the pumping
chamber.
WARNING Flame Prohibited
3. DISCHARGE FUEL
(See Fig.
88
88
8
-
tt
tt
t)
4. ENGINE OIL (See Fig.
88
88
8
-
yy
yy
y,
uu
uu
u)
■

Change the engine oil with fresh oil.
■

Remove the spark plug, pour about 5 cc of engine oil
into the cylinder, slowly pull the starter handle of the recoil
starter 2 or 3 times, and reinstall the spark plug.
5. CLEAN AND STORE
■

Slowly pull the recoil starter handle until resistance is felt
and leave it in that position.
■

Clean the pump thoroughly with an oiled cloth, put the
cover on, and store the pump indoors in a well ventilated,
low humidity area.
Take extreme caution when replacing fuel hose ;
gasoline is extremely flammable.
WARNING
