Robin 109 - Symbols; Components; Centrifugal Pump (PTG109)

4
GB
Read the owner's manual.
Stay clear of the hot surface.
Exhaust gas is poisonous.
Do not operate in an unventilated area.
Stop the engine before refueling.
Fire, open flame and smoking prohibited.
On (Run) Plus ; Positive polarity
Off (Stop) Battery
Engine oil
Engine start
(Electric start)
Add oil
2. COMPONENTS
(See Fig.
11
11
1)
SYMBOLS
q Tank cap
w Recoil starter
e Starter handle
r Spark plug cap
t Speed control lever
y Air cleaner
u Primer button
i Choke lever
o Muffler
!0 Stop Switch
!1 Fuel tank
!2 Plug (drain)
!3 Casing cover
!4 Suction
CENTRIFUGAL PUMP (PTG109)
(See Fig.
11
11
1
-
qq
qq
q)
!5 Delivery
!6 Plug (priming)
!7 Strainer
!8 Hose coupling
!9 Hose band
@0 Tools
@1 Instruction for use
(This publication)
NOTE Please refer to the illustrations on the back page of the front
cover or back cover for Fig.
1 1
1 1
1 to
ii
ii
i indicated in the sentence.
