13
-
4-17 SECTIONAL VIEW OF ENGINE
Fig. 4-16
MUFFLER
P.T.O. SHAFT
AIR CLEANER
CARBURETOR
RECOIL STARTER
FLYWHEELMAIN BEARING COVER
