Robin EH36BS User Manual

- 35 -
5-4-7-1 CRANKSHAFT END PLAY (For type D and type B)
1) Measure the depth “A1” (From the mating surface to the inner race of the ball bearing.)
2) Measure the height “B1” (From the mating surface to the crank gear.)
(A1+0.35) - B1= SIDE CLEARANCE (mm)
(SIDE CLEARANCE)
- 0.2 mm = THICKNESS OF CRANKSHAFT SHIM (mm)
(A1+0.014)
- B1= SIDE CLEARANCE (in.)
(SIDE CLEARANCE)
- 0.008 in.= THICKNESS OF CRANKSHAFT SHIM (in.)
Following are available spacer shims.
5-4-7-2 CAMSHAFT END PLAY (For type D and type B)
1) Measure the depth “A2” (From the mating surface to the inner race of the ball bearing.)
2) Measure the height “B2” (From the mating surface to the cam gear inner boss.)
(A2+0.35)
- B2= SIDE CLEARANCE (mm)
(SIDE CLEARANCE)
- 0.2 mm = THICKNESS OF CAMSHAFT SHIM (mm)
(A2+0.014)
- B2= SIDE CLEARANCE (in.)
(SIDE CLEARANCE)
- 0.008 in.= THICKNESS OF CAMSHAFT SHIM (in.)
Following are available spacer shims.
Table. 5-2
Table. 5-1
TFAHSKNARC
SMIHSRECAPS
).ni420.0(mm6.0=T
).ni130.0(mm8.0=T
).ni930.0(mm0.1=T
TFAHSMAC
DepytroFBepytroF
SMIHSRECAPS
).ni420.0(mm6.0=T
).ni820.0(mm7.0=T
).ni130.0(mm8.0=T
).ni420.0(mm6.0=T
).ni130.0(mm8.0=T
).ni930.0(mm0.1=T
