Robin EHO9-2D User Manual

– 36 –
18.15
(0.715)
18.3 - 18.5
(0.720 - 0.728)
IN. / EX.
9.95
(0.3917)
9.972 - 9.987
(0.3926 - 0.3932)
D1
9.95
(0.3917)
9.972 - 9.987
(0.3926 - 0.3932)
D2
IN.
EX.
CAMSHAFT
* Cam height (IN. and EX.)
5.35
(0.2106)
5.426 - 5.444
(0.2136 - 0.2143)
5.35
(0.2106)
5.440 - 5.455
(0.2142 - 0.2148)
IN.
EX.
0.3
(0.012)
0.056 - 0.092
(0.0022 - 0.0036)
0.3
(0.012)
0.045 - 0.078
(0.0018 - 0.0031)
* Clearance between valve stem dia. and valve
guide.
* Valve clearance
(cold)
0.07 - 0.13
(0.0028 - 0.0051)
* Journal outside dia.
"D" type
VALVE
* Valve stem outside dia.
D
1 D2
ITEM
STD Limit
Unit : mm (in.)

Robin EHO9-2D Specifications
