EX13, EX17, EX21 - 9 - 07-03
SECTION 2 CRANKSHAFT GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 276-20901-21 CRANKSHAFT CP 1 3/4” key, 5/16 tap - EX13 200
276-21001-21 CRANKSHAFT CP 1 5/8” Pump - EX13 200
276-21201-21 CRANKSHAFT CP 1 SAE Taper - EX13 200
276-20201-31 CRANKSHAFT CP 1 Metric 18mm - EX13 200
276-20301-21 CRANKSHAFT CP 1 Metric pump 18mm - EX13 200
276-20701-21 CRANKSHAFT CP 2 Metric Taper - EX13 200
10 277-20901-21 CRANKSHAFT CP 1 3/4” key, 5/16 tap - EX17 200
277-21001-21 CRANKSHAFT CP 1 5/8” Pump - EX17 200
277-21201-21 CRANKSHAFT CP 1 SAE Taper - EX17 200
277-20201-21 CRANKSHAFT CP 1 Metric 20mm - EX17 200
277-20301-21 CRANKSHAFT CP 1 Metric Pump 20mm - EX17 200
277-20701-21 CRANKSHAFT CP 1 Metric Taper - EX17 200
10 278-20901-31 CRANKSHAFT CP 1 3/4” key, 5/16 tap - EX21 200
278-21001-31 CRANKSHAFT CP 1 5/8” Pump - EX21 200
278-21201-31 CRANKSHAFT CP 1 SAE Taper - EX21 200
278-20201-31 CRANKSHAFT CP 1 Metric 20mm - EX21 200
278-20301-21 CRANKSHAFT CP 1 Metric Pump 20mm - EX21 200
278-20701-21 CRANKSHAFT CP 1 Metric Taper - EX21 200
50 018-01400-20 FLANGE NUT 1 200
70 032-30300-10 WOODRUFF KEY 1 200
310 276-22501-10 CONNECTING ROD AY 1 EX13 200
277-22501-10 CONNECTING ROD AY 1 EX17 200
278-22501-10 CONNECTING ROD AY 1 EX21 200
320 277-23001-03 CONNECTING ROD BOLT 2 200
350 276-23301-03 PISTON PIN 1 EX13 200
277-23301-03 PISTON PIN 1 EX17 and EX21 200
360 276-23401-03 PISTON 1 EX13 - STD 200
276-23403-03 PISTON 1 EX13 - Oversize 0.25mm 200
276-23404-03 PISTON 1 EX13 - Oversize 0.55mm 200
277-23401-03 PISTON 1 EX17 and EX21 - STD 200
277-23403-03 PISTON 1 EX17 and 21 Oversize 0.25mm 200
277-23404-03 PISTON 1 EX17 and EX21 Oversize 0.50mm 200
370 276-23511-17 PISTON RING SET 1 EX13 - STD 200
276-23512-17 PISTON RING SET 1 EX13 - Oversize 0.25mm 200
276-23513-17 PISTON RING SET 1 EX13 - Oversize 0.50mm 200
277-23511-17 PISTON RING SET 1 EX17 and EX21 - STD 200
277-23512-17 PISTON RING SET 1 EX17 and EX21 Oversize 0.25mm 200
277-23513-17 PISTON RING SET 1 EX17 and EX21 Oversize 0.50mm 200
380 215-25004-03 CLIP 2 EX13 200
056-51600-10 CLIP 2 EX17 and EX21 200
