EX13, EX17, EX21 - 11 - 07-03

REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.

10 277-31601-11 CAMSHAFT CP 1 2100000~ 300

25 277-35101-03 PIN, camshaft 1 2100000~ 300

27 024-00600-10 O RING 1 2100000~ 300

34 277-38601-03 PIN, spring 1 2100000~ 300

35 277-36401-03 RELEASE LEVER 1 2100000~ 300

37 277-36501-03 CLIP 1 2100000~ 300

38 277-38702-03 RETURN SPRING 1 2100000~ 300

60 279-33601-03 VALVE SPRING 2 2100000~ 300

70 269-33701-03 RETAINER VALVE SPRING 2 2100000~ 300

80 276-33401-33 INTAKE VALVE 1 EX13 2100000~ 300

277-33401-13 INTAKE VALVE 1 EX17 and EX21 2100000~ 300

90 276-33501-33 EXHAUST VALVE 1 EX13 2100000~ 300

277-33501-13 EXHAUST VALVE 1 EX17 and EX21 2100000~ 300

95 132-10KA0-31 COLLET VALVE 4 2100000~ 300

150 276-35601-11 TIMING CHAIN CP 1 EX13 2100000~ 300

277-35601-11 TIMING CHAIN CP 1 EX17 2100000~ 300

278-35601-11 TIMING CHAIN CP 1 EX21 2100000~ 300

160 277-36911-03 TENTIONER 1 2100000~ 300

163 277-37101-03 SPRING, tentioner 1 2100000~ 300

166 277-36902-03 PIN, tentioner 1 2100000~ 300

170 277-36913-13 CHAIN GUIDE 1 2100000~ 300

200 277-35002-03 PIN, rocker 1 2100000~ 300

210 003-13050-00 CLIP 1 2100000~ 300

220 277-36201-00 ROCKER ARM AY, in 1 2100000~ 300

225 277-36202-00 ROCKER ARM AY, ex 1 2100000~ 300

230 014-90500-20 ADJUST SCREW 2 2100000~ 300

240 017-00500-30 NUT 2 2100000~ 300

290 011-00600-20 FLANGE BOLT 1 2100000~ 300

310 276-30101-11 MUFFLER CP 1 EX13 2100000~ 300

277-30101-11 MUFFLER CP 1 EX17 2100000~ 300

278-30101-11 MUFFLER CP 1 EX21 2100000~ 300

310 276-30111-01 MUFFLER CP 1 EX13, w/ spark arrestor 2100000~ 300

277-30111-01 MUFFLER CP 1 EX17,21, w/ spark arrestor 2100000~ 300

315 277-37601-01 SPARK ARRESTOR 1 2100000~ 300

317 015-00400-60 TAPPING SCREW 1 2100000~ 300

320 277-34201-11 MUFFLER COVER 1 2100000~ 300

340 277-35201-13 GASKET, mufﬂ er 1 2100000~ 300

350 980-20082-80 FLANGE NUT 2 2100000~ 300

360 015-20600-90 TAPPING BOLT 2 2100000~ 300

361 011-00600-10 FLANGE BOLT 1 2100000~ 300

365 011-00801-50 FLANGE BOLT 1 2100000~ 300

385 277-37203-01 SCREEN CP 1 2100000~ 300

387 015-00400-60 TAPPING SCREW 2 2100000~ 300

440 277-37001-01 DEFLECTOR CP 1 2100000~ 300

445 015-00400-60 TAPPING SCREW 2 2100000~ 300

SECTION 3 INTAKE and EXHAUST GROUP - NEW STYLE
