Robin EX13D Instructions For Use

EX13, EX17, EX21 - 13 - 07-03
SECTION 3 INTAKE and EXHAUST GROUP - OLD STYLE
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 277-31601-01 CAMSHAFT CP 1 ~2099999 300
25 277-35101-03 PIN, camshaft 1 ~2099999 300
27 024-00600-10 O RING 1 ~2099999 300
34 277-38601-03 PIN, spring 1 ~2099999 300
35 277-36401-03 RELEASE LEVER 1 ~2099999 300
37 277-36501-03 CLIP 1 ~2099999 300
38 277-38701-03 RETURN SPRING 1 ~2099999 300
60 279-33601-03 VALVE SPRING 2 ~2099999 300
70 269-33701-03 RETAINER VALVE SPRING 2 ~2099999 300
80 276-33401-33 INTAKE VALVE 1 EX13 ~2099999 300
277-33401-13 INTAKE VALVE 1 EX17 and EX21 ~2099999 300
90 276-33501-33 EXHAUST VALVE 1 EX13 ~2099999 300
277-33501-13 EXHAUST VALVE 1 EX17 and EX21 ~2099999 300
95 132-10KA0-31 COLLET VALVE 4 ~2099999 300
150 276-35601-01 TIMING CHAIN CP 1 EX13 ~2099999 300
277-35601-01 TIMING CHAIN CP 1 EX17 ~2099999 300
278-35601-01 TIMING CHAIN CP 1 EX21 ~2099999 300
160 277-36911-03 TENTIONER 1 ~2099999 300
163 277-37101-03 SPRING, tentioner 1 ~2099999 300
166 277-36902-03 PIN, tentioner 1 ~2099999 300
170 277-36913-13 CHAIN GUIDE 1 ~2099999 300
200 277-35001-23 PIN, rocker 1 ~2099999 300
220 277-36101-00 ROCKER ARM AY, in 1 ~2099999 300
225 277-36102-00 ROCKER ARM AY, ex 1 ~2099999 300
230 014-90500-10 ADJUST SCREW 1 ~2099999 300
231 014-90500-10 ADJUST SCREW 1 ~2099999 300
240 017-00500-20 NUT 1 ~2099999 300
241 017-00500-20 NUT 1 ~2099999 300
290 011-00600-20 FLANGE BOLT 1 ~2099999 300
310 276-30101-11 MUFFLER CP 1 EX13 ~2099999 300
277-30101-11 MUFFLER CP 1 EX17 ~2099999 300
278-30101-11 MUFFLER CP 1 EX21 ~2099999 300
276-30111-01 MUFFLER CP 1 EX13 - w/spark arrestor ~2099999 300
277-30111-01 MUFFLER CP 1 EX17,EX21 - w/ spark arrestor ~2099999 300
315 277-37601-01 SPARK ARRESTOR 1 ~2099999 300
317 015-00400-60 TAPPING SCREW 1 ~2099999 300
320 277-34201-01 MUFFLER COVER 1 ~2099999 300
340 277-35201-03 GASKET, muffl er 1 ~2099999 300
350 980-20082-80 FLANGE NUT 2 ~2099999 300
360 015-20600-90 TAPPING BOLT 2 ~2099999 300
361 011-00600-10 FLANGE BOLT 1 ~2099999 300
365 011-00801-50 FLANGE BOLT 1 ~2099999 300
440 277-37001-03 DEFLECTOR 1 ~2099999 300
445 015-00400-60 TAPPING SCREW 2 ~2099999 300
