EX13, EX17, EX21 - 17 - 07-03
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
510 277-32613-00 AIR CLEANER AY 1 Cyclone Pre-Cleaner 320C
277-32620-10 AIR CLEANER AY 1 Low Profi le 320D
-200 277-32630-08 BASE CP 1 320C
277-32613-18 BACK PLATE 1 320D
-210 277-32604-08 GASKET 1 320C
-220 277-32610-08 PACKING 1 320C
277-32604-08 GASKET 1 320D
-250 277-32641-08 COVER 1 320C
277-32612-28 COVER 1 320D
-260 277-32609-08 LABEL 1 320C
-270 277-32741-08 WING NUT 1 320C
-272 277-32607-08 WING NUT 1 320C
-310 277-32770-08 ROTARY BLADE, CUP 1 320C
-315 277-32750-08 SCREW 2 320C
520 277-32611-07 ELEMENT AY 1 Cyclone Pre-Cleaner 320C
277-32614-07 ELEMENT SET 1 Low Profi le 320D
SECTION 3 INTAKE and EXHAUST GROUP
