EX13, EX17, EX21 - 19 - 07-03
SECTION 4 GOVERNOR GROUP - New Style
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 277-42301-13 GOVERNOR LEVER 1 2100000~ 400
20 277-42201-33 GOVERNOR SHAFT 1 2100000~ 400
30 279-42701-01 GOVERNOR ROD CP 1 EX13 2100000~ 400
30 277-42701-01 GOVERNOR ROD CP 1 EX17 and EX21 2100000~ 400
40 277-42801-13 ROD SPRING 1 2100000~ 400
50 003-13050-00 CLIP 1 2100000~ 400
60 013-00602-40 BOLT and WASHER AY 1 2100000~ 400
70 018-60600-20 NUT 1 2100000~ 400
80 279-42502-23 GOVERNOR SPRING 1 2100000~ 400
310 277-43303-01 SPEED CONTROL LEVER 1 2100000~ 400
340 277-43501-03 STOP PLATE 1 2100000~ 400
350 020-00601-70 WASHER 1 2100000~ 400
355 021-70600-70 FRICTION WASHER 1 2100000~ 400
360 004-31062-50 SCREW 1 2100000~ 400
365 237-45004-23 SPRING 1 2100000~ 400
395 277-43902-03 CLAMP 1 2100000~ 400
396 013-10500-30 SCREW and WASHER AY 1 2100000~ 400
435 277-46002-01 SPEED CONTROL BRKT 1 2100000~ 400
440 004-31040-80 SCREW 1 2100000~ 400
450 002-35060-00 SELF LOCK NUT 1 2100000~ 400
480 267-45101-03 RETURN SPRING 1 2100000~ 400
485 011-00600-20 FLANGE BOLT 2 2100000~ 400
486 277-43701-01 LINK ROD 1 2100000~ 400
277-46003-00 SPEED CONTROL AY 1 Incl. the following items: 2100000~
310,340,350,355,360,365,395,
396,435,440,450,480,486
