Robin EX13D - Page 37

EX13, EX17, EX21 - 25 - 07-03
SECTION 5 COOLING and STARTING GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
210 268-50201-30 RECOIL STARTER AY 1 EX13 510
269-50201-30 RECOIL STARTER AY 1 EX17 510
278-50201-20 RECOIL STARTER AY 1 EX21 510
-1 270-50115-08 SPIRAL SPRING 1 510
-2 269-50120-08 REEL 1 510
-3 582-50111-18 STARTER ROPE 1 510
-4 261-50100-08 STARTER KNOB 1 510
-5 270-50125-08 RATCHET 2 510
-6 227-50131-08 FRICTION SPRING 1 510
-11 268-50145-18 STARTER PULLEY 1 EX13 510
269-50145-18 STARTER PULLEY 1 EX17 510
278-50145-08 STARTER PULLEY 1 EX21 510
-35 270-50261-08 RATCHET GUIDE 1 510
-49 227-50152-08 SET SCREW 1 510
