EX13, EX17, EX21 - 27 - 07-03
SECTION 6 FUEL, LUBRICATION GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 276-60102-01 FUEL TANK CP 1 EX13, Black 600
276-60101-11 FUEL TANK CP 1 EX13, Yellow 600
277-60102-01 FUEL TANK CP 1 EX17 and EX21, Black 600
277-60101-11 FUEL TANK CP 1 EX17 and EX21, Yellow 600
20 073-20051-81 LABEL, warning 1 600
23 276-95101-03 LABEL, model 1 EX13 600
277-95101-03 LABEL, model 1 EX17 600
278-95101-03 LABEL, model 1 EX21 600
30 043-04300-60 FUEL TANK CAP CP 1 leakproof 600
40 064-13600-10 FUEL FILTER 1 600
48 050-51200-20 UNION 1 600
60 002-38060-00 FLANGE NUT 2 600
63 011-00601-30 FLANGE BOLT 1 600
80 085-10600-00 RUBBER PIPE 1 600
90 X56-11000-30 HOSE CLAMP 2 600
224 277-43801-01 CHOKE LEVER CP 1 600
225 REMOTE CHOKE CONTROL 1 600
226 SPRING 1 600
227 GASKET 1 600
395 277-43902-03 CLAMP 1 600
396 013-10500-30 SCREW and WASHER 1 600
440 004-31040-80 SCREW 1 600
540 277-32902-H3 INSULATOR 1 600
550 277-35902-H3 GASKET 1, insulator 1 600
560 277-35903-H3 GASKET 2, insulator 1 600
