− 34−
RGV4100
V
+
-
120V 120V
120/240V 120/240V
REC1
W
W
REC3
GENERATOR CONTROL BOX
Field Winding
AC Winding 2 AC Winding 1
DC Winding
Diode
Surge absorber
Auxiliary Winding for condenser
2.0Blu 2.0Blk
No-fuse breaker
2.0R
Voltmeter
1.25Y
1.25Brn
Condenser
2.0W
1.25Or
1.25Brn/W
DC output terminal
Circuit breaker
Diode stack Assy
Earth (Ground) terminal
Full power switch
Idle
control
unit
AC output
receptacle
(
120V
)
AC output
receptacle
(
120/240V
)
Idle control switch
ENGINE
0.75W
0.75W
Solenoid
0.75Blu
Charge coil
Ignition coil
Spark plug
Engin switch
1.25Y
Condenser
1.25Brn
1 5 3 4 2
1 5 3 4 2
0.75W 0.75W 0.75Blu 0.75LBlu
AC output
receptacle
(
120V
)
REC2
W
2.0Grn
0.75Blk
0.75W
0.75W0.75Grn/Y
0.75Blk
0.75LBlu
0.75Blk
Oil sensor
0.75Grn/Y
0.75Blk
No-fuse breaker
RGV28-61(CSA)英取説GU203104.10.286:55PMページ34
