Robin RGV2800 User Manual

ENGLISH
− 33−
12. WIRING DIAGRAM
RGV2800
V
+
-
REC1
Field Winding
Diode
Surge absorber
Auxiliary Winding for condenser
AC Winding 1AC Winding 2
1.25Grn 1.25Brn 1.25Brn 1.25Y 1.25Y 2.0W
2.0Blk2.0R
Voltmeter
No-fuse breaker
AC output receptacle (
120V
)
Condenser
Engine switch
1.25Blk
DC output terminal
1.25Brn/W
1.25Or
Circuit breaker
Diode stack Assy
2.0Grn
Earth (Ground) terminal
0.75Grn/Y
0.75Grn/Y
0.75Blk
Oil sensor
0.75Blk
Ignition coil
Spark plug
GRNERATOR CONTROL BOX ENGINE
DC Winding
W
0.75
Wiring color cord
Blk Black Brn/W Brown/White R Red Blk/W Black/White Grn Green W White
Blu Blue
Grn/W Green/White Y
Yellow
LBlu Light blue Org Orange Brn
Brown Gry Gray
: :
: : :
:
: :
: :
:
: :
