Setting the Date/Time
The date set will be the date recorded on all the result records. Once set the date and time is automati-
cally incremented, but should be checked on switch on before commencing any tests. To adjust the date
and time:
Press DATE button, the following is displayed:
Enter date, press GO
19/08/1999 08:40:25
If no change is required press GO button, display will return to the main screen
The cursor will be highlighting the first character of the date. If a change is required enter the date,
followed by the time in the following format, using the keypad.
dd/mm/yy hh:mm
On completion of the operation press GO button, display will return to the main screen.
Setting the Site
This allows a site to be identified and subsequent tests to be recorded for/under the site. A recognition
code is entered, so that the place of testing (site) is registered on all result records. Failure to set the
site recognition code will result in the code entered for the last site being recorded on all the result
records. Once a site as been allocated to a record it is not possible to amend the record, only to delete it.
If no change is required remain with the main screen, no further action is necessary. To set a new site
code:
Press SITE button, the following is displayed:
Enter site, press GO
…………
The cursor will be highlighting the first character of the code. Enter required site code using buttons on
the keypad as detailed in Use of Alpha Numeric Keypad at the start of the Installation section
On completion of the operation press GO button, display will return to the main screen
The SmartPAT 5500 is now ready to commence testing the appliances.
SmartPAT 5500
11
