Robin SmartPAT 5500 - Page 14

Table 2 Automatic Tests
Test No Tests Time Pass/Fail point
101 Visual check
26A earth bond test 10s 0.1ohm
Insulation, Class 1 10s 2.0Mohm
Load: load 10s 3kVA
leakage 1.0mA
102 Visual check
26A earth bond test 10s 0.1ohm
Insulation, Class 1 10s 2.0Mohm
Flash 10s 1.0mA
Load: load 10s 3kVA
leakage 1.0mA
103 Visual check
100mA earth bond test 10s 0.1ohm
Insulation, Class 1 10s 2.0Mohm
Load: load 10s 3kVA
leakage 1.0mA
201 Visual check
Insulation, Class II 10s 7.0Mohm
Load: load 10s 3kVA
leakage 10s 1.0mA
202 Visual check
Insulation, Class II 10s 7.0Mohm
Flash 10s 1.0mA
Load: load 10s 3kVA
leakage 10s 1.0mA
301 Visual check
8A earth bond test 0.1ohm
Insulation test 7.0Mohm
Note
The results shown in the following tests have typical values for example purposes.
To perform an auto test the procedure is as follows:
Press AUTO key, the following is displayed:
Enter the Autotest
Number, press GO
After 2 seconds the display changes:
Autotest
Autotest number: 101
SmartPAT 5500
13
