Press GO key, the following screen is displayed:
Insulation Class I
Test in progress 10
The test is of 10 seconds duration, this is counted down by the numeric counter in the display. The result
of the test is then displayed. If the test fails you will then see a message similar to
Fig 1.
Insulation Class I
Resistance >300MΩ
After a few seconds the test changes as shown on screen:
Load/Leakage 230V
Press GO to start
Press GO key to continue the following screen is displayed:
Load/Leakage 230V
Testing Fuse
If the fuse is OK the screen will display:
Fuse Intact
Press GO to continue
If the fuse is not OK the screen will display:
Fuse Appears Blown
or Low Load Rating
And after a few seconds the screen will display:
Continue? Or Re-Test Fuse?
GO/YES/NO
If the GO is pressed the unit will proceed to a Load/Leakage Test.This will flag the fuse test as a pass and
must only be done after the fuse has been checked manually. If the YES (UP) Key is pressed the unit will
re-test the fuse. If the NO key is pressed the unit will record the Load/Leakage Test as a fail result.The above
procedure allows you the option of checking or replacing the fuse if the tester identifies a problem with the
fuse.Any problem must be corrected prior to continuation of any testing if a fail result is to be avoided.
While the test is in progress for the 10 seconds, the 230V displayed is alternated with a WARNING sign.
Press GO key to continue.The unit will proceed to a Load/Leakage Test.
The user should exercise caution with the equipment as the appliance under test will power up during
the test sequence. On completion of the test the results are displayed:
Load/Leakage
VoltAmp 838VA
After a few seconds the screen changes to show the leakage current:
Load/Leakage
Leakage 0.0mA
After a few seconds the display changes to the screen below. If the test fails you will then see a
message similar to
Fig 1.
Autotest complete
Use REVIEW or STORE
SmartPAT 5500
15
