5
Installation – Recirculation
If you do not have a vent leading outside, the rangehood can be installed in recirculation mode. Activated carbon
filters will be used to filter the air and recirculate it back into the room. Installation is similar to the installation
method for exhaust above, but without the duct.
Once the rangehood has been mounted and the chimney has been installed (see previous pages), the activated
carbon filters need to be installed.
Remove the grease filter by pressing the lock and pulling down.
Attach the carbon filter onto the motor and turn it clockwise to lock it in. Repeat for the other side.
Note: Ensure that the carbon filter is properly locked in place. If it is not, it can fall off and cause damage.
When the carbon filter is attached, the unit’s suction power will be impacted.
