Robomow RS - Base Station Installation Steps; Charging Adaptor Handling; Wire Connection; Stake Installation

7 8
10
9
11 12
13
14 15
17 16
Base Station Installation
Remove charging adaptor
Chap. 2.6.3
A - Pull
B - Push
Assemble adaptor
Chap. 2.6.3
Insert 2 stakes
Chap. 2.7
Connect the wires
Chap. 2.6.3
Power Box Installation
Chap. 2.8
Mount Bracket
Connect 20m extension cable
12
11
13
Add pegs
Insert fuse
Chap. 3.1
Follow instructions on Robomow LCD
Chap. 3.3.1- 3.3.3
Setup complete
One-Time Setup
