Main Parts
Robomow
®
1. Operating Lamp
2. Bumper with touch sensitive sensors
3. STOP Button / Carrying Handle
4. Operating Panel
Under the Hood
1. Bumper Door
2. Mowing Height Indicator
3. Mowing Adjustment Knob
4. Safety Switch
Base Station
1. Base Station Head (Charging Adaptor)
2. Base
3. Flippers (x2)
4. Stakes (x6)
Power Box
1. Docking Indicator
2. ON/OFF button
3. Operating Indicator
4. Wire Indicator
1
2
3
4
1
3
2
4
4 3 2 1
1
2
4
3
