09
Routine Maintenance
D
*
Clean every 2 weeks and replace every 6-12 months
D1-1—Main Brush Cover
D1-2—Latches
D1-3—Main Brush
D1-4—Main Brush Caps
D1-5—Main Brush Bearing
D1-6—Turn over the robot and press the
latches to remove the main brush cover.
D1-7—Pull out the main brush and remove
the main brush bearing. Rotate the
main brush caps in the indicated
unlock direction to remove the caps,
and remove any entangled hair or
dirt at both ends of the main brush.
D1-8—Reinstall the main brush.
D1-9—Reinstall the main brush cover. Make
sure that the four teeth are fully seated
in the slot, and then press on the
main brush cover to lock it.
D1
Main Brush
Notes:
•
Main brush should be wiped down with wet cloth and
left to dry away from direct sunlight.
•
Do not use corrosive cleaning fluids or disinfectants to
clean the main brush.
D2
Side Brush
*
Clean monthly and replace every 3-6 months
Unscrew the side brush screw. Remove and
clean the side brush. Reinstall the brush
and tighten the screw.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle and take out the
wheel.
The omnidirectional wheel bracket cannot be removed.Note:
D3
Omnidirectional Wheel
*
Clean as required
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Dry and reattach the wheel, pressing
it firmly in place.
Clean the main wheel with a soft, dry cloth.
D4
Main Wheel
*
Clean monthly
D5
Dustbin
D5-1—Open the top cover of the robot and
press the dustbin latch to take out
the dustbin.
*
Clean as required
To prevent blockage, only use clean water without
any cleaning liquid.
Note:
D5-2—Open the washable filter and empty
the dustbin.
D5-3—Fill the dustbin with clean water and
reinstall the washable filter. Gently
shake the dustbin, and then pour out
the dirty water.
D5-4—Leave the dustbin and the washable
filter to dry.
D6
Washable Filter
D6-1—Remove the filter.
D6-2—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
D6-3—Allow 24 hours for the filter to dry
thoroughly and reinstall it.
*
Clean every two weeks and replace the filter every 6-12 months
Do not touch the surface of the filter with your
hands, brush, or hard objects to avoid potential damage.
Note:
D7
Mop Cloths
D7-1—Remove the mop cloth from the mop
cloth mount. Clean the mop cloth and
air-dry it.
D7-2—Stick the mop cloth on the mount in
position and firmly.
*
Clean as required and replace every 1-3 months
A dirty mop cloth will affect the cleaning performance.
Clean it before use.
Note:
D8
Robot Sensors
Use a soft, dry cloth to wipe and clean all
sensors, including:
D8-1—Dock Locator
D8-2—Reactive Tech Obstacle Avoidance
Sensor
D8-3—Wall Sensor
D8-4—Mop Wash Sensor
D8-5—The Carpet Sensor
D8-6—Four Cliff Sensors
*
Clean monthly
