10
Model
EWFD11HRR or
EWFD12HRR
Rated Input Voltage 220-240VAC
Rated Frequency 50-60Hz
Rated Input
(Dust Collection)
4A
Rated Input
(Non-Dust Collection)
0.55A
Rated Output 20VDC 1.5A
Battery
14.4 V/5200 mAh
(TYP) lithium-ion
battery
D9
Moving Dock
Lift up and move the dock. Do not move the
dock by lifting dock base, water tank handles
or dust container cover directly to prevent the
dock from falling off.
D10
Dirty Water Tank
Open the dirty water tank lid and pour out
the dirty water. Fill the tank with clean water,
close the lid, and shake. Pour out the dirty
water. Close the lid and then re-install.
*
Clean as required
D11
Charging Contact Areas
Use a soft dry cloth to wipe the charging
contacts on the robot and the dock.
*
Clean monthly
Notes:
•
The dust bag handle seals the bag on removal to prevent
leakage.
•
Always install a dust bag before closing the dust container
cover to avoid auto-emptying without the bag. You can
also disable auto-emptying in the app.
D12
Replacing Disposable Dust Bag
D12-1—Remove the dust container cover.
D12-2—Remove the disposable dust bag in the
direction of the arrow and discard it.
*
Replace as required
Empty Wash Fill Dock
D12-4—Close the cover of the dust container
and make sure it is securely sealed.
D13
Cleaning Tank
D13-1—Remove the cleaning tank.
D13-2—Rinse the cleaning tank and the filter
with water.
D13-3—Reinstall the cleaning tank.
*
Clean as required
Basic Parameters
Robot
The serial number is on a sticker on the underside
of the robot.
Note:
D12-3—Clean around the filter with a dry
cloth. Install a new disposable dust
bag in place along the slot and
unfold the dust bag to maximize
emptying performance.
Model QX0PEA
Battery
14.4 V/5200 mAh (TYP)
lithium-ion battery
Rated Input 20VDC 1.5A
Charging Time Approx. 4 hours
To Next Page
