10
Auto-emptying will automatically begin when
the robot returns to the dock after cleaning.
To manually start emptying, press
button
on the docked robot or tap Empty button in
the app. Press any button to stop emptying.
Emptying
•
When auto-emptying has been left unused for a long
period, empty the dustbin manually and make sure
the air inlet is clear for optimal emptying performance.
•
Auto emptying can be disabled through the app.
•
Avoid frequent manual emptying.
Notes:
Drying starts automatically after mop
washing or after cleaning are completed.
To manually start or stopping drying, tap
Drying button in the app.
Drying
•
Modify the drying duration in the app.
•
Auto drying can be disabled through the app.
Notes:
Routine Maintenance
D
*
Clean every 2 weeks and replace every 6-12 months.
D1-1—Main Brush Cover
D1-2—Latches
D1-3—Main Brush
D1-4—Main Brush Caps
D1-5—Main Brush Bearing
D1-6—Turn over the robot and press the
latches to remove the main brush cover.
D1-7—Pull out the main brush and remove
the main brush bearing.
D1-8—Remove the main brush cap, rotating
in the unlock direction. After cleaning,
reattach it turning in the lock direction.
D1-9—After removing the tangled hair or
dirt at both ends of the main brush,
reinstall it, press on the main brush
cover to lock it in place.
D1
Main Brush
D3
Omnidirectional Wheel
D4
Main Wheel
Notes:
•
Main brush should be wiped down with wet cloth and
left to dry away from direct sunlight.
•
Do not use corrosive cleaning uids or disinfectants to
clean the main brush.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle and take out the
wheel.
The omnidirectional wheel bracket cannot be
removed.
Note:
*
Clean as required.
*
Clean monthly.
D2
Side Brush
*
Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Dry and reattach the wheel, pressing
it rmly in place.
Clean the main wheel with a soft, dry cloth.
D5
Dustbin
D5-1—Open the top cover of the robot and
press the dustbin latch to take out
the dustbin.
*
Clean as required.
To prevent blockage, only use clean water without
any cleaning liquid.
Note:
D5-2—Press the cover latch to open the
dustbin cover and remove the washable
lter, then empty the dustbin.
D5-3—Fill the dustbin with clean water and
close the cover. Gently shake the
dustbin, and then pour out the dirty
water. Leave the dustbin and the
washable lter to dry.
tank relling to maximize its mopping
performance. To manually start washing,
tap Wash button in the app or press and
hold the
button on the robot to send it
back. Press any button to stop washing.
•
To allow the robot to wash the mop automatically,
start the robot from the dock and do not move the
dock during cleaning.
•
Mop washing duration is 20 minutes by default and you
can modify this duration or washing mode in the app.
Notes:
To Next Page
