SAFETY
These models are fitted with a magnetic safety
device and motor braking system.
As soon as you open the lid of the cutter bowl or
the vegetable attachment, the motor stops.
To restart the machine, simply close the lid and
press the green switch.
In order to avoid splashing when processing liquid
preparation, we recommend you stop the machine
before opening the lid.
All the models are fitted with a thermal cut-out
which automatically stops the motor if the machine
is left on for too long or overloaded.
If this happens, allow the machine to cool completely
before restarting.
• WORKING HEIGHT
We recommend that you position the food processor
on a stable worktop so that the upper edge of the large
feed hopper is at a height of between 1.20 m and
1.30 m.
• NOISE LEVEL
The equivalent continuous sound level when the
food processor is operating on no-load is less than
70 db (A).
• ELECTRICAL DATA
R 5 Plus single-phase machine
R 5 Plus three-phase machines
R 5 V.V. single-phase machines
R 6 three-phase machines
R 6 V.V. single-phase machines
• DIMENSIONS (in mm)
R 5 Plus R 5 V.V. R 6 R 6 V.V.
A 480 480 520 520
B 350 350 350 350
C 280 280 280 280
D 265 265 265 265
Motor
Speed
(rpm)
Intensity
(amp.)
230 V/50 Hz 1,500 6
220 V/60 Hz 1,500 6
Motor
Speed
(rpm)
Intensity
(amp.)
230 V/50 Hz 300 to 3,000 12
Motor
Speed
(rpm)
Intensité
(amp.)
230 V/50 Hz 300 to 3,000 13
Motor
Speed 1
(rpm)
Speed 2
(rpm)
Intensité
(amp.)
230 x 400 V/50 Hz
1,500
230V = 4.4
400V = 2.5
3,000
230V = 7.0
400V = 4.0
400 V/50 Hz
1,500 2.7
3,000 3.4
220 V/60 Hz
1,800 4.7
3,600 6.5
Motor
Speed 1
(rpm)
Speed 2
(rpm)
Intensity
(amp.)
230 x 400 V/50 Hz
1,500
230V = 4.4
400V = 2.5
3,000
230V = 7.0
400V = 4.0
400 V/50 Hz
1,500 2.7
3,000 3.4
220 V/60 Hz
1,800 4.7
3,600 6.5
W A R N I N G
The blades are extremely sharp.
Handle with care.
- Power shown on data plate.
