26
SAFETY
These models are fitted with a magnetic safety
device and motor braking system.
As soon as you open the lid of the cutter bowl or
the vegetable attachment, the motor stops.
To restart the machine, simply close the lid and
press the green switch.
Three-phase machine R 652
Single-phase machine R 652 V.V.
- Power shown on data plate.
• WORKING HEIGHT
We recommend that you position the food proces-
sor on a stable worktop so that the upper edge of
the large feed hopper is at a height of between
1.20 m and 1.30 m.
• NOISE LEVEL
The equivalent continuous sound level when the
food processor is operating on no-load is less than
70 db (A).
• ELECTRICAL DATA
Three-phase machine
• BLADES, COMBS AND GRATERS
That blades on the silicing discs, the combs on the
julienne discs and the graters are all wearing parts,
which have to be changed every so often to ensure
high quality cutting.
TECHNICAL
SPECIFICATIONS
• WEIGHT
Net Gross
R 502 (without disc) 30 kg 32 kg
R 502 V.V. (without disc) 34 kg 36 kg
R 652 (without disc) 32,5 kg 37,5 kg
R 652 V.V. (without disc) 34,5 kg 39,5 kg
• DIMENSIONS (in mm)
Single-phase machine R 502 V.V.
W A R N I N G
The blades and discs are extremely sharp.
Handle with care.
Motor
Veg prep
speed
(rpm)
Cutter
speed
(rpm)
Intensity
(Amp.)
230 V/50-60 Hz 300 to 1000 300 to 3500 13
Motor
Veg prep
speed
(rpm)
Cutter
speed
(rpm)
Intensity
(Amp.)
230 V/50-60 Hz 300 to 1000 300 to 3500 12
Motor
Veg prep
speed
(rpm)
Cutter
speed
(rpm)
Intensity
(Amp.)
230 x 400 V/50 Hz
750
230V=3,1
400V=1,8
1500
230V=3,6
400V=2,1
400 V/50 Hz
750 2,2
1500 2,4
220 V/60 Hz
900 3,6
1800 3,8
380 V/60 Hz
900 2,1
1800 2,2
Motor
Veg prep
speed
(rpm)
Cutter
speed
(rpm)
Intensity
(Amp.)
230 x 400 V/50 Hz
750
230V=3,1
400V=1,8
1500
230V=3,6
400V=2,1
400 V/50 Hz
750 2,2
1500 2,4
220 V/60 Hz
900 3,6
1800 3,8
380 V/60 Hz
900 2,1
1800 2,2
ABCDE FG
R 502 / R 502 V.V.
480 347 280 265 395 378 300
R 652 / R 652 V.V.
520 347 280 265 434 378 335
