Robot Compact PRO - Table of Contents

To Next Page

To Previous Page

Content

1. Introduction 01

1.1 Manufacturer, copyright 01

1.2 Disclaimer 01

2. Warnings/safety measures 02

2.1 Safety instructions 02

2.2 Required personal protection equipment 04

3. Product description/product overview 05

3.1 Compact PRO manifold 05

3.2 Optimum Flow PRO manifold 08

3.3 District heating PRO manifold 10

3.4 LT manifold 12

3.5 Setting of the PRO-valve 13

3.6 Pumps 14

3.6.1 Wilo Para HU 25/6-43/SCU 14

4. Storage and transport 15

4.1 Storage 15

4.2 Transport 15

5. Mounting preparation 16

5.1 Mounting conditions 16

5.2 Tools overview 17

6. Installing/mounting 18

6.1 Installation of a manifold 18

6.2 Connecting the manifold to the central heating system 20

 6.3 Connectingtheunderoorheatingpipetothemanifold  20

 6.4 Fillingandventingtheunderoorheatingsystem   22

7. Commissioning/decommissioning 24

7.1 Putting into operation/setting the manifold 24

7.2 Setting of the PRO-valve on Standard and 25

Optimum Flow manifolds

8. Maintenance & service 26

9. Failures 27

9.1 Troubleshooting 27

10. Environment/waste disposal 28

11. Guarantee 28

12. Contact 28

Appendices

Notes

Publication: 2020
