FBL2360 Brushless DC Motor Controller Datasheet 19
Electrical Specifications
Pwr
CtrlVMOTGND M1+M1-M2+M2-M3+M3-
I/O ConnectorHall Sensors
Connector
USB
Connector
LEDs
5.50" (139 .7mm)
5.50" (139.7mm)
3.00" (76.2mm)1.25" (31.8mm)
0.24" (6.0mm)
5.00" (127.0mm)
FIGURE 15. FBL2360 top view and dimensions
Revision Date Additions/Changes
1. 1 April 23, 2019 Added T-version with STO support
1. 2 May 21, 2019 STO certification change
1. 3 August 29, 2019 UL certification changes
Revision history
