Robotis BIOLOID GP - Assembly Guide: Part 12 (Steps 21-22); Head Frame, LED, and Battery Cable Connection

26
STEP
21
CM-510 right side
LED BOARD
STEP
22
Attach head frame and LED Board. ( attention to the direction of 5P-CABLE)
Attach head frame to chest frame, the connect a 5P-CABLE to port 5 of the CM-510.
Connect the battery cable (CABLE-BAT) to the CM-510.
(Tip : run the CABLE-BAT under the body to main better wiring organization)
Connect the other end of CABLE-BAT to the battery pack cable.
26
