Page #1 background image

Loading...

Page #1 background image

N° d

i serie S/N

Manufacturing year

2016

Type

RB-DV

Operating and maintenance

instructions for blowers.

Instruction for

Transport | Installation | Operation | Maintenance

PD Blower & Vacuum Pump Service & Repair Facility

120 – 10293 276 ST, Acheson, Alberta, Canada T7X 6A5

T: 780.962.1827 F: 780.962.1830 E: sales@fraserwoods.ca

Table of Contents

Questions and Answers:

A
Andrea FordAug 5, 2025
Why is my Robuschi RB-DV 65/V Blower making unusual noises and/or vibrations?
- S
  Shawn HallAug 5, 2025
  If your Robuschi Blower is experiencing unusual noises or vibrations, it could be due to several reasons. One possibility is that the rotors are making contact. Immediately stop the blower and check the internal clearances of the rotors and the gear. Another cause might be scale deposits in the compression chamber. In this case, you should clean the compression chamber and the rotors, balancing the rotors if necessary. Also, the issue might be the intake of foreign particles. Remove the foreign particles, clean the compression chamber, and check the clearances.
A
atorresAug 9, 2025
What to do if the Robuschi Blower motor hums but doesn't start?
- J
  Jennifer RiveraAug 9, 2025
  If your Robuschi Blower motor doesn't start but makes a humming noise, there could be a few reasons. It might be that at least two of the electric connections have been cut off, or that one electric connection has been cut off. In both cases, check the fuses, terminal boards, and connection cables, and replace them if necessary. Another possibility is an incorrect electric connection, so you should check the electric system. Finally, the motor itself could be faulty, so check the electric motor.
R
Robert HopkinsAug 14, 2025
How to fix a Robuschi RB-DV 65/V Blower when the motor doesn't start and there's no noise?
- P
  Paul GayAug 14, 2025
  If your Robuschi Blower motor does not start up and there is no noise, it could be due to several reasons: * At least two of the electric connections have been cut off. * One electric connection has been cut off. In both cases, check the fuses, terminal boards, and connection cables, and replace them if required. It could also be due to an incorrect electric connection, so check the electric system. Another possibility is a faulty motor, in which case you should check the electric motor.
M
Maria HoffmanAug 18, 2025
What to do if my Robuschi RB-DV 65/V Blower automatically cuts off after starting?
- J
  Joshua DunnAug 18, 2025
  If your Robuschi Blower experiences automatic cut off just after start up, there could be several reasons. One possibility is that at least two of the electric connections have been cut off, or that one electric connection has been cut off. In both cases, you should check the fuses, terminal boards, and connection cables, replacing them if necessary. It could also be due to an incorrect electric connection, so check the electric system. Another possibility is a faulty motor, so check the electric motor. Finally, the issue might be the intake of foreign particles, so remove the foreign particles, clean the compression chamber, and check the clearances.
C
Chelsea MeyerAug 22, 2025
Why does my Robuschi RB-DV 65/V have high absorbed power?
- J
  Jaime GloverAug 22, 2025
  High absorbed power in your Robuschi Blower can be caused by scale deposits in the compression chamber. Clean the compression chamber and the rotors, and balance the rotors if necessary. Another cause might be the intake of foreign particles. Remove the foreign particles, clean the compression chamber and check the clearances.
B
Barbara HartmanAug 27, 2025
How to stop oil or liquid from leaking in my Robuschi RB-DV 65/V Blower?
- M
  Melissa DavisAug 27, 2025
  If you notice oil and/or liquid leakage in your Robuschi Blower, it could be due to worn gaskets. If this is the case, replace the gaskets. Another cause could be a worn drive shaft seal, which would require replacing the seal. Also, check if the oil level plugs are broken and replace the oil levels if needed.
J
joan60Aug 31, 2025
What causes high oil temperature in my Robuschi RB-DV 65/V?
- B
  Brendan WalkerAug 31, 2025
  If your Robuschi Blower is experiencing high oil temperature, it could be due to a damaged cooling circuit (only /RV models). In this case, you should restore the circuit.

Robuschi RB-DV 65/V Specifications

General

Type	Rotary Lobe Blower
Model	RB-DV 65/V
Nominal Size	65 mm
Pressure	Up to 1000 mbar (g)
Inlet/Outlet Connection	Flanged

Summary

GENERAL INFORMATION

Qualified Personnel Definition

Safety Warnings and Definitions

Key safety warnings and definitions for understanding the manual.

SAFETY INFORMATION

Blower Operation Safety

Precautions and warnings for operating the blower safely.

Pre-Service Safety Procedures

Steps to ensure safety before performing any service on the blower.

In-Service Safety Precautions

Safety measures to follow while performing service on the blower.

PERFORMANCE LIMITS AND WORKING CONDITIONS

Operating Environment and Gas Type

Specifies suitable operating environments and conveyed gases for the blower.

Performance Limits Table

Table detailing maximum/minimum limits for pressure, temperature, and speed.

Flow Adjustment Methods

FORBIDDEN USES AND RESIDUAL RISKS

Forbidden Operational Uses

List of uses that are forbidden for the blower and associated risks.

Identified Residual Risks

Overview of residual risks associated with blower operation and maintenance.

INSTALLATION GUIDELINES

On-Site Blower Positioning

Instructions for correctly positioning the blower on its installation site.

Inlet/Outlet Arrangement Modification

Direction of Rotation and Gas Flow

COUPLING PROCEDURES

Direct Coupling Alignment

BELT DRIVE COUPLING

Belt Drive Pulley Selection

Belt Tensioning and Alignment

SYSTEM PIPING REQUIREMENTS

General Piping Guidelines

Vacuum Operation Piping

Pressure Operation Piping

COOLING AND ELECTRICAL CONNECTIONS

Cooling Circuit Setup (/RV Models)

Electrical Connection Requirements

Guidelines for safe and compliant electrical connections.

BLOWER OPERATION AND CONTROL

Preliminary Checks Before Operation

Essential checks to perform before starting the blower.

First Start-Up Procedure

Step-by-step guide for the initial start-up of the blower.

Routine Operation Monitoring

Stopping the Blower Safely

MAINTENANCE PROCEDURES

Oil Change Intervals and Procedures

Details on when and how to perform oil changes for the blower.

Oil Type and Viscosity Selection

Recommended Mineral Oils

COMPONENT MAINTENANCE

Replacing the Shaft Seal

Cleaning the Compression Chamber

Checking Gear and Rotor Clearances

DISASSEMBLY AND REASSEMBLY

Disassembly Procedures

Reassembly Procedures
