Page #1 background image

Loading...

Page #1 background image

N° d

i serie S/N

Manufacturing year

2016

Type

RB-DV

Operating and maintenance

instructions for blowers.

Instruction for

Transport | Installation | Operation | Maintenance

PD Blower & Vacuum Pump Service & Repair Facility

120 – 10293 276 ST, Acheson, Alberta, Canada T7X 6A5

T: 780.962.1827 F: 780.962.1830 E: sales@fraserwoods.ca

Table of Contents

Questions and Answers:

K
Kevin HarrisAug 5, 2025
Why is my Robuschi RBS making unusual noises and/or vibrations?
- L
  Lauren LambAug 5, 2025
  If your Robuschi Blower is experiencing unusual noises or vibrations, it could be due to several reasons. One possibility is that the rotors are making contact. Immediately stop the blower and check the internal clearances of the rotors and the gear. Another cause might be scale deposits in the compression chamber. In this case, you should clean the compression chamber and the rotors, balancing the rotors if necessary. Also, the issue might be the intake of foreign particles. Remove the foreign particles, clean the compression chamber, and check the clearances.
J
Jacqueline WrightAug 10, 2025
What to do if the Robuschi RBS motor hums but doesn't start?
- T
  Todd GutierrezAug 10, 2025
  If your Robuschi Blower motor doesn't start but makes a humming noise, there could be a few reasons. It might be that at least two of the electric connections have been cut off, or that one electric connection has been cut off. In both cases, check the fuses, terminal boards, and connection cables, and replace them if necessary. Another possibility is an incorrect electric connection, so you should check the electric system. Finally, the motor itself could be faulty, so check the electric motor.
S
Stephanie WestAug 14, 2025
How to fix a Robuschi RBS Blower when the motor doesn't start and there's no noise?
- B
  Benjamin WashingtonAug 14, 2025
  If your Robuschi Blower motor does not start up and there is no noise, it could be due to several reasons: * At least two of the electric connections have been cut off. * One electric connection has been cut off. In both cases, check the fuses, terminal boards, and connection cables, and replace them if required. It could also be due to an incorrect electric connection, so check the electric system. Another possibility is a faulty motor, in which case you should check the electric motor.
A
Amanda MooreAug 18, 2025
What to do if my Robuschi Blower automatically cuts off after starting?
- A
  arandolphAug 18, 2025
  If your Robuschi Blower experiences automatic cut off just after start up, there could be several reasons. One possibility is that at least two of the electric connections have been cut off, or that one electric connection has been cut off. In both cases, you should check the fuses, terminal boards, and connection cables, replacing them if necessary. It could also be due to an incorrect electric connection, so check the electric system. Another possibility is a faulty motor, so check the electric motor. Finally, the issue might be the intake of foreign particles, so remove the foreign particles, clean the compression chamber, and check the clearances.
M
Mark BaileyAug 23, 2025
Why does my Robuschi Blower have high absorbed power?
- P
  Patricia EvansAug 23, 2025
  High absorbed power in your Robuschi Blower can be caused by scale deposits in the compression chamber. Clean the compression chamber and the rotors, and balance the rotors if necessary. Another cause might be the intake of foreign particles. Remove the foreign particles, clean the compression chamber and check the clearances.
J
juliamillerAug 27, 2025
How to stop oil or liquid from leaking in my Robuschi RBS Blower?
- L
  Linda JacksonAug 27, 2025
  If you notice oil and/or liquid leakage in your Robuschi Blower, it could be due to worn gaskets. If this is the case, replace the gaskets. Another cause could be a worn drive shaft seal, which would require replacing the seal. Also, check if the oil level plugs are broken and replace the oil levels if needed.
M
Michelle JohnsonAug 31, 2025
What causes high oil temperature in my Robuschi RBS Blower?
- H
  hannah20Aug 31, 2025
  If your Robuschi Blower is experiencing high oil temperature, it could be due to a damaged cooling circuit (only /RV models). In this case, you should restore the circuit.

Robuschi RBS Specifications

General

Stages	Single-stage
Pressure	Up to 1000 mbar
Vacuum	Up to 500 mbar
Construction	Cast iron
Cooling	Air-cooled
Applications	Wastewater treatment, pneumatic conveying

Summary

RB-DV Blower Operating and Maintenance Manual

General Information

Safety Symbols and Qualified Personnel Definition

Defines warning symbols, notes, and requirements for authorized personnel.

Safety Information

Customer Responsibilities for Installation Environment

Operational Safety Precautions

Details safety rules for blower operation, including temperature and proximity warnings.

Service Safety Procedures and Warnings

Outlines essential safety steps before and during blower service operations.

Blower Identification and Warranty Conditions

Warranty Terms and Exclusions

Details the blower's warranty period, coverage, and limitations.

Performance Limits and Working Conditions

Operating Environment and Conveyed Gas Specifications

Performance Limits and Operating Parameters

Provides specific operating parameters like RPM, pressure, and temperature limits.

Forbidden Uses and Residual Risks

Forbidden Uses and Associated Risks

Lists prohibited operations and their potential consequences for the blower and personnel.

Residual Risks and Mitigation Advice

Identifies potential hazards and residual risks, with advice for mitigation.

Installation Guidelines

Blower Positioning and Mounting

Details how to position and attach the blower securely on a level surface.

Inlet and Outlet Arrangement Changes

Correct Rotation and Gas Flow Direction

Specifies the correct rotation direction and gas flow for standard blower operation.

Coupling and Piping Installation

Direct Coupling Installation Procedure

Belt Drive Coupling Installation

System Piping and Support Requirements

Electrical and Cooling System Setup

Electrical Connection Standards and Safety

Requirements for safe and compliant electrical connections by authorized specialists.

Operation Procedures

Preliminary Checks Before First Start

First Start-Up and Initial Monitoring

Step-by-step guide for initiating the blower and initial operational checks.

Routine Operation Monitoring and Checks

Safe Blower Stopping Procedure

Maintenance Procedures

Oil Change Schedule and Procedure

Instructions for performing oil changes, including quantity and timing.

Recommended Lubricant Types and Viscosity

Troubleshooting Guide

Common Blower Operating Problems and Causes

Table correlating common operating problems with their potential causes.

Solutions for Identified Blower Issues

Provides solutions and references for troubleshooting various blower problems.

Disassembly and Reassembly Procedures

General Disassembly Precautions and Warnings

Drive Side Sump Disassembly and Reassembly

Gear Side Sump Disassembly and Reassembly
