Robustel R1510 Hardware Manual
RT048_HM_R1510 8/10
Hardware Installation
1. SIM Card Installation. Insert the SIM cards into the device, then stick the sticker.
2. Antenna Installation. Rotate the antenna into the antenna connector accordingly.
3. Terminal Block Installation. Insert the 2PIN、3PIN terminal blocks into the interfaces connector.
4. Mounting Kit installation.
1
Wall mounting
