Rocal ARc 76 LD - Specifications; Requirements Prior to Installation

9
1.1 Tehnical specifications
Parámetro
Modelo
ARc 76 LD
ARc 76 LI
ARc 76 LD +Plus 180
ARc 76 LI +Plus 180
ARc 96 LD
ARc 96 LI
Minimum - Maximum draught 11-13 Pa 11-13 Pa 11-13 Pa
Fuel consumption 2,74 kg/h 2,8 kg/h 2,86 kg/h
Smoke mass flow rate 8,77 g/s 10,8 g/s 11,86 g/s
Efficiency 84 % 77,3 % 81 %
Nominal output 9,7 kW 9,4 kW 10,2 kW
Power range
6,5 – 11 kW 6,5 – 11 kW 7 – 12 kW
Average CO concentration at 13% of O2
0,09 % 0,08 % 0,067 %
NOx concentration at 13% of O2
100,17 mg/Nm
3
104 mg/Nm
3
100 mg/Nm
3
OGC concentration at 13% of O2 93,34 mg/Nm
3
66 mg/Nm
3
57 mg/Nm
3
Particle concentration at 13% of O2 27,68 mg/Nm
3
16,4 mg/Nm
3
11 mg/Nm
3
Medium draft (trial) 12 Pa 11,2 Pa 11,5 Pa
Net weight 136 kg 153,9 kg 187 kg
Maximum authorized load (fuel) 4 kg 4 kg 5 kg
Reload height 200 mm 200 mm 200 mm
Logs length
400 mm 400 mm 500 mm
Minimum flue height
4000 mm 4000 mm 4000 mm
Ø Flue duct
180 mm 180 mm 180 mm
Ø Air inlet
100 mm 100 mm 100 mm
Ø Air outlet 120 mm 120 mm 120 mm
Fireplace safety distances (back) 200 mm 200 mm 200 mm
Fireplace safety distances (side) 200 mm 200 mm 200 mm
Fireplace safety distances (glass side) 1000 mm 1000 mm 700 mm
Fireplace safety distances (frontal) 1000 mm 1000 mm 1500 mm
Fireplace room ventilation (entry - exit) 450 cm
2
450 cm
2
450 cm
2
Cableado eléctrico de conexión
Silicone hose 3*wire of 1.5 mm
2
Flujo aire turbinas (unidad)
135 m
3
/h
Potencia turbinas (unidad)
20 W
Distancia seguridad mín. a las salidas de aire 250 mm
Temperatura media de humos
204ºC
270 ºC
2
93,7
ºC
Tipo de combustión
INTERMITENT
Conducto
NOT SHARED
Combustible
NATURAL WOOD
Humedad
leños combustible
12
-
20 %
-
two years under cover
Año Certificación
2019
2019
2022
Nº de Certificado
19/20678
-
1854
-
1/2
1880
-
CPR
-
014
-
19
1880
-
CPR
-
026
-
22
1.2 Breakdown of delivery components
(Make sure you have all the components described below in relation to the picture on section II of the ANNEXED document)
1.
Fireplace’s body.
2.
Heat-resistant spray paint for touch-ups.
3.
Fire grate.
4.
Heat-resistant glove.
5. 2x Outlet hot air connector (ARc 76 LD, ARc 76 LD +Plus 180, ARc 76 LI, ARc 76 LI +Plus 180). 4x Outlet hot air connector
(ARc 96 LD, ARc 96 LI)
6.
Cleaning cloth
7.
Exterior air inlet kit. (Exterior air inlet connector, connector support, tubular joint, metallic anchor, screws and nuts)
8.
Tool for handling registers and opening door.
9.
Bag with screws.
10. Documentation bag: output declaration, energy label, guarantee, technical sheet, and installation and operating
characteristics manual.
11.
+Plus 180 (ARc 76 LD +Plus 180, ARc 76 LI +Plus 180)
12.
Draught limiter
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I, page 1.
ALL LOCAL STANDARDS, INCLUDING NATIONAL AND EUROPEAN REGULATIONS MUST BE COMPLIED WITH UPON
INSTALLATION OF THE EQUIPMENT.
THE INSTALLATION MUST BE PERFORMED BY A PROFESSIONAL. FAILURE TO COMPLY WITH THIS CLAUSE SHALL
EXONERATE THE MANUFACTURER FROM ANY RESPONSIBILITY.
