Rocal ARc DC 80 - Specifications; 1.1 Technical Specifications; 1.2 Breakdown of Delivery Components; 1.3 Diagram of Equipment Measurements

8
1.1 Technical specifications
* Values obtained in the laboratory of Manufacturas Rocal
1.2 Breakdown of delivery components
(Make sure you have all the components described below in relation to the picture on section II of the ANNEXED document)
1.
Fireplace’s body.
2.
Heat-resistant spray paint for touch-ups.
3.
Heat-resistant glove.
4.
Cleaning cloth
5.
Outdoor air intake Kit. (Outdoor air intake connector, support for the connector, tubular seal and screws)
6.
Tool for handling registers and opening door.
7. Documentation bag: output declaration, energy label, guarantee, technical sheet, and installation and operating
characteristics manual.
8.
Outlet hot air connector
9.
Bag with screws
10.
+ Plus 180 (ARc 80 DC +Plus 180, ARc 100 DC +Plus 180)
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I, page 1.
ALL LOCAL STANDARDS, INCLUDING NATIONAL AND EUROPEAN REGULATIONS MUST BE COMPLIED WITH UPON
INSTALLATION OF THE EQUIPMENT.
Parameter
Model
ARc 80 DC*
ARc 80 DC
+Plus 180
ARc 100 DC*
ARc 100 DC
+Plus 180
Minimum - Maximum draught 11-13 Pa 11-13 Pa 11-13 Pa 11-13 Pa
Fuel consumption 3,7 3,35 kg/h 4 kg/h 4 kg/h
Smoke mass flow rate 16,3 g/s 14,3 g/s 17,5 g/s 19,5 g/s
Efficiency ≥70 % 85,7 % ≥68 % 75,9%
Nominal output 11,5 kW 12,4 kW 13 kW 13,4 kW
Power range 8 – 14 kW 8,5 – 14,5 kW 9,5 - 15 kW 9 – 15 kW
Average CO concentration at 13% of O2 ≤ 0,18 % 0,107 % ≤ 0,20 % 0,10 %
NOx concentration at 13% of O2 **** 108 mg/Nm
3
**** 102 mg/Nm
3
OGC concentration at 13% of O2 **** 141 mg/Nm
3
**** 81 mg/Nm
3
Particle concentration at 13% of O2 **** 34 mg/Nm
3
**** 16,30 mg/Nm
3
Medium draft (trial) 12 Pa 12,5 Pa 12 Pa 13,3
Net weight 160 kg 177,9 kg 216 kg 223,9 kg
Maximum authorized load (fuel) 4 kg 4 kg 5 kg 5 kg
Reload height 200 mm 200 mm 200 mm 200 mm
Logs length 400 mm 400 mm 500 mm 500 mm
Minimum flue height 4000 mm 4000 mm 4000 mm 4000 mm
Ø Flue duct 180 mm 180 mm 180 mm 180 mm
Ø Air inlet 100 mm 100 mm 100 mm 100 mm
Ø Air outlet 120 mm 120 mm 120 mm 120 mm
Inner fireplace room safety distances (back) 1000 mm 1000 mm 1000 mm 1000 mm
Inner fireplace safety distances (sides) 50 mm 50 mm 50 mm 50 mm
Outer fireplace safety distances (back) 1000 mm 1000 mm 1000 mm 1000 mm
Outer fireplace safety distances (sides) 750 mm 750 mm 750 mm 750 mm
Outer fireplace safety distances (frontal) 1000 mm 1000 mm 1000 mm 1000 mm
Fireplace room ventilation (entry - exit) 450 cm
2
450 cm
2
450 cm
2
450 cm
2
Minimum safety distance to the air outlets 250 mm
Average temperature of smoke 225,4 ºC 138,8 ºC 222,8 ºC 217 ºC
Type of combustion INTERMITENT
Flue liner NOT SHARED
Fuel NATURAL WOOD
Humidity fuel logs 12-20 % - 2 YEARS UNDER COVER
Certification year **** 2019 **** 2019
Certificate number **** 1800-CPR-020-19 **** 1800-CPR-038-19
1. SPECIFICATIONS
2. REQUIREMENTS PRIOR TO INSTALLATION
