Rocal INSERT ARc 50V - Specifications

10
1.1 Technical specifications
Parameter
Model
ARc 50V
ARc 50V
+Plus 150
ARc 65
ARc 65
+Plus 180
ARc 80
ARc 80
+Plus 180
Minimum - Maximum draught 11 -13 Pa 11-13 Pa 11-13 Pa 11-13 Pa 11-13 Pa 11 -13 Pa
Fuel consumption 2 kg/h 2,31 kg/h 2,60 kg/h 2,35 kg/h 2,8 kg/h 2,47 kg/h
Smoke mass flow rate 5,4 g/s 5,4 g/s 7,6 g/s 6,6 g/s 9,9 g/s 9,7 g/s
Efficiency 77,16 % 86,3% 77 % 85,3 % 77 % 85,3 %
Nominal output 6,3 kW 8,7 kW
8 kW
8,75 kW 10 kW 9 kW
Power range 5,5 - 9,5 kW 4 – 9 kW 5,5 – 10 kW 5,5 - 10 kW 6,5 - 11,5 kW 6,5 - 11,5 kW
Average CO concentration at 13% of O2
0,0564 % 0,048 % 0,099 % 0,062 % 0,099 % 0,062 %
NOx concentration at 13% of O2 98 mg/Nm3 102 mg/Nm
3
107 mg/Nm
3
106 mg/Nm3 107 mg/Nm3 106 mg/Nm3
OGC concentration at 13% of O2 53 mg/Nm3 51 mg/Nm
3
66 mg/Nm
3
51 mg/Nm3 66 mg/Nm3 51 mg/Nm3
Particle concentration at 13% of O2 23 mg/Nm3 13 mg/Nm
3
24 mg/Nm
3
23 mg/Nm3 24 mg/Nm3 23 mg/Nm3
Medium draft (trial) 11 Pa 8,4 Pa 11 Pa 8,4 Pa 11 Pa 8,6 Pa
Net weight 98 kg 114 kg 92 kg 108 kg 121 kg 138,9 kg
Maximum authorized load (fuel) 3 kg 2,5 kg 3 kg 4 kg 4 kg 4 kg
Reload height 200 mm 175 mm 175 mm 200 mm 200 mm 200 mm
Logs length 330 mm 330 mm 500 mm 450 mm 500 mm 500 mm
Minimum flue height 4000 mm 4000 mm 4000 mm 4000 mm 4000 mm 4000 mm
Ø Flue duct 150 mm 150 mm 180 mm 150 mm 180 mm 180 mm
Ø Air inlet 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm
Ø Air outlet 120 mm 120 mm 120 mm 120 mm 120 mm 120 mm
Safety distances (back) 150 mm 150 mm 150 mm 150 mm 150 mm 150 mm
Safety distances (sides) 150 mm 150 mm 150 mm 150 mm 150 mm 150 mm
Safety distances (frontal) 1000 mm 1000 mm 1000 mm 1000 mm 1000 mm 1000 mm
Fireplace room ventilation (entry - exit) 450 cm
2
450 cm
2
450 cm
2
450 cm
2
450 cm
2
450 cm
2
Electrical wiring connection Silicone hose 3*wire of 1.5 mm
2
Fan airflow (unit) 135 m
3
/h
Fan output (unit) 20 W
Minimum safety distance to the air outlets 250 mm
Average temperature of smoke
316º C 220,8ºC 322ºC 220,8ºC 313ºC 196,8ºC
Type of combustion INTERMITENT
Flue liner NOT SHARED
Fuel NATURAL WOOD
Humidity fuel logs 12-20 % - two years under cover
Certification year 2016 2019 2022 2022 2021 2019
Certificate number 30-13474-T |
E
-
30
-
00014
-
18
1880-CPR-001-19 1880-CPR-018-
008
-
21
1880-CPR-008-
013
-
19
1880-CPR-018-
006
-
21
1880-CPR-001-19
Parameter
Model
ARc 70
ARc 70
+Plus 150
ARc 70A
ARc 70A
+Plus 150
ARc 70C
ARc 70C
+ Plus 150
Minimum - Maximum draught 11-13 Pa 11-13 Pa 11-13 Pa 11-13 Pa 11-13 Pa 11-13 Pa
Fuel consumption 2,66 kg /h 2,37 kg/h 2,66 kg /h 2,37 kg/h 2,66 kg /h 2,37 kg/h
Smoke mass flow rate 7,6 g/s 6,6 g/s 7,6 g/s 7,6 g/s 7,6 g/s 6,6 g/s
Efficiency 77% 85,3% 77% 85,3% 77% 85,3%
Nominal output 9.1 kW 8,8 kW 9,1 kW 8,8 kW 9.1 kW 8,8 kW
Power range 6 – 10.5 kW 6 – 10.5 kW 6 – 10.5 kW 6 – 10.5 kW 6 – 10.5 kW 6 – 10.5 kW
Average CO concentration at 13% of O
2
(%)
0,099 % 0,062 % 0,099% 0,062 % 0,099 % 0,062 %
NOx concentration at 13% of O2
:
(mg/Nm
3
)
107 mg/Nm
3
106 mg/Nm
3
91 mg/Nm3 106 mg/Nm
3
107 mg/Nm
3
106 mg/Nm
3
OGC concentration at 13% of O2
:
(mg/Nm
3
)
66 mg/Nm
3
51 mg/Nm
3
49 mg/Nm3 51 mg/Nm
3
66 mg/Nm
3
51 mg/Nm
3
Particle concentration at 13% of O2(mg/Nm
3
)
24 mg/Nm
3
22,9 mg/Nm
3
24 mg/Nm3 22,9 mg/Nm
3
24 mg/Nm
3
22,9 mg/Nm
3
Medium draft (trial) 13 Pa 8,4 Pa 13 Pa 8,4 Pa 13 Pa 8,4 Pa
Net weight 97 kg 113 kg 103 kg 119 kg 92 kg 108 kg
Maximum authorized load (fuel) 3 kg 3 kg 3 kg 3 kg 3 kg 3 kg
Reload height 175 mm 175 mm 175 mm 175 mm 175 mm 175 mm
Logs length 400 mm 400 mm 400 mm 400 mm 400 mm 400 mm
Minimum flue height 4000 mm 4000 mm 4000 mm 4000 mm 4000 mm 4000 mm
Ø Flue duct 150 mm 150 mm 150 mm 150 mm 150 mm 150 mm
Ø Air inlet 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm
Ø Air outlet 120 mm 120 mm 120 mm 120 mm 120 mm 120 mm
Safety distances (back) 150 mm 150 mm 150 mm 150 mm 150 mm 150 mm
Safety distances (sides) 150 mm 150 mm 150 mm 150 mm 150 mm 150 mm
Safety distances (frontal) 1000 mm 1000 mm 1000 mm 1000 mm 1000 mm 1000 mm
Fireplace room ventilation (entry - exit) 450 cm
2
450 cm
2
450 cm
2
450 cm
2
450 cm
2
450 cm
2
Electrical wiring connection Silicone hose 3*wire of 1.5 mm
2
Fan airflow (unit) 135 m
3
/h
Fan output (unit) 20 W
Minimum safety distance to the air outlets 250 mm
Average temperature of smoke
322º C 220,8ºC 322º C 220,8ºC 322º C 220,8ºC
Type of combustion INTERMITENT
Flue liner NOT SHARED
Fuel NATURAL WOOD
Humidity fuel logs 12-20 % - two years under cover
Certification year 2021 2019 2021 2019 2021 2019
Certificate number 1880-CPR-018-
004
-
21
1880-CPR-001-19 1880-CPR-18-21 1880-CPR-001-19 1880-CPR-018-
004
-
21
1880-CPR-1-19
1.
SPECIFICATIONS
