Rocal INSERT ARc 50V - Requirements Prior to Installation

11
Parameter
Model
ARc 100R
ARc 100R
+Plus 180
ARc 100
ARc 100
+Plus 180
Minimum - Maximum draught 11 -13 Pa 11 -13 Pa 11 -13 Pa 11 -13 Pa
Fuel consumption 3,1 kg/h 2,8 kg/h 3,18 kg/h 3,19 kg/h
Smoke mass flow rate 9,9 g/s 9,7 g/s 9,9 g/s 9,7 g/s
Efficiency 77 % 85,3 % 79,6 % 86,2 %
Nominal output 10,5 kW 11 kW 11,1 kW 12,1 kW
Power range 7,5 - 12,5 kW 7,5 - 12,5 kW 7,5 - 13 kW 7,5 - 13 kW
Average CO concentration at 13% of O2
0,099 % 0,09 % 0,091 % 0,09 %
NOx concentration at 13% of O2 107 mg/Nm3 106 mg/Nm3 107 mg/Nm3 101 mg/Nm3
OGC concentration at 13% of O2 66 mg/Nm3 59 mg/Nm3 66 mg/Nm3 59 mg/Nm3
Particle concentration at 13% of O2 24 mg/Nm3 23 mg/Nm3 12 mg/Nm3 18 mg/Nm3
Medium draft (trial) 11 Pa 8,6 Pa 11,6 Pa 11,4 Pa
Net weight 121 kg 169 kg 143 kg 160,9 kg
Maximum authorized load (fuel) 4,5 kg 4,5 kg 5 kg 4 kg
Reload height 200 mm 200 mm 200 mm 200 mm
Logs length 400 mm 400 mm 600 mm 600 mm
Minimum flue height 4000 mm 4000 mm 4000 mm 4000 mm
Ø Flue duct 180 mm 180 mm 180 mm 180 mm
Ø Air inlet 100 mm 100 mm 100 mm 100 mm
Ø Air outlet 120 mm 120 mm 120 mm 120 mm
Safety distances (back) 150 mm 150 mm 150 mm 150 mm
Safety distances (sides) 150 mm 150 mm 150 mm 150 mm
Safety distances (frontal) 1000 mm 1000 mm 1000 mm 1000 mm
Fireplace room ventilation (entry - exit) 450 cm
2
450 cm
2
450 cm
2
450 cm
2
Electrical wiring connection
Silicone hose 3*wire of 1.5 mm
2
Fan airflow (unit)
135 m
3
/h
Fan output (unit)
20 W
Minimum safety distance to the air
outlets
250 mm
Average temperature of smoke
3
22
º C
211,3 ºC
279ºC
196,8ºC
Type of combustion
INTERMITENT
Flue liner
NOT SHARED
Fuel
NATURAL WOOD
Humidity fuel logs
12
-
20 %
-
two years under cover
Certification year
2022
2022
20
21
2019
Certificate number
1880
-
CPR
-
039
-
004
-
21
1880
-
CPR
-
041
-
006
-
21
1880
-
CPR
-
39
-
21
1880
-
CPR
-
041
-
21
1.2 Breakdown of delivery components
( Make sure you have all the components described below in relation to the picture on section II of the ANNEXED document)
1.
Fireplace’s body.
2.
Heat-resistant spray paint for touch-ups.
3.
Fire grate.
4.
Heat-resistant glove.
5. 2x Outlet hot air connector (ARc 50V, ARc 50V + Plus 150, ARc 65, ARc 65 +Plus 150, ARc 70, ARc 70 + Plus 150, ARc
70A, ARc 70A + Plus 150, ARc 70C, ARc 70C + Plus 150). 4x Outlet hot air connector (ARc 80, ARc 80 + Plus 180, ARc
100R, Arc 100R + Plus180, ARc 100, ARc 100 + Plus 180)
6.
Cleaning cloth for metal painted parts
7.
Exterior air inlet kit. (Exterior air inlet connector, connector support, tubular joint, metallic anchor, screws and nuts)
8.
Tool for handling registers and opening door.
9. 8x screws (ARc 50V, ARc 50V + Plus 150, ARc 65, ARc 65 +Plus 150, ARc 70, ARc 70 + Plus 150, ARc 70A, ARc 70A +
Plus 150, ARc 70C, ARc 70C + Plus 150) | 16x screws (ARc 80, ARc 80 + Plus 180, ARc 100R, Arc 100R + Plus180, ARc
100, ARc 100 + Plus 180) to install outlet hot air connectors.
10. Documentation bag: output declaration, energy label, guarantee, technical sheet, and installation and operating
characteristics manual.
11.
Optional: + Plus 150 (ARc 50 + Plus 150 | ARc 65 + Plus 150 | ARc 70 + Plus 150 | ARc 70A + Plus 150 | ARc 70C + Plus
150) | + Plus 180 (ARc 80 + Plus 180 | ARc 100R + Plus 180 | ARc 100 + Plus 180)
12.
Packaging. The wooden pallet can be used as fuel or recycled. Other packaging items must be recycled or disposed of
13.
Draft limiter
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I
ALL LOCAL STANDARDS, INCLUDING NATIONAL AND EUROPEAN REGULATIONS MUST BE COMPLIED WITH
UPON INSTALLATION OF THE EQUIPMENT.
THE INSTALLATION MUST BE PERFORMED BY A PROFESSIONAL. FAILURE TO COMPLY WITH THIS CLAUSE SHALL
EXONERATE THE MANUFACTURER FROM ANY RESPONSIBILITY.
2.1 Ground. Make sure the ground where the appliance will be placed is able to support the weight of the device. If not, you will need
a load spreading plate for the equitable distribution of the equipment's weight. In case of doubt, please consult a specialist.
2.2 Flue liner. It is mandatory to have a smoke-tight Flue liner going from the connecting point of the base to the outside in observation
of the smoke pipe diameter. The good condition and suitability of this smoke pipe must be certified by a professional and
must also observe the relevant national regulations. This flue liner must be T400 and G type should not be shared with other
devices (see Table 1.1 Technical specifications). In cases of too much draught, when the duct exceeds 7 meters in length, or the
measurement exceeds 20 Pa, the draft must be adjusted. To do this, use the second part of the baffle plate, to install it follow the
steps: "D.9" to "D.12" or adjust the air intake through the grille go to Section 4.4.1 Primary Registrer.
2. REQUIREMENTS PRIOR TO INSTALLATION
