Rocket Espresso Boxer series espresso machines: Hydraulic circuit.

Pos. Description

A Boiler

B Heat exchanger

1 Water inlet pipe

2 Water inlet filter

3 Pump

4 Valve block

5 Manual boiler fill

6 Non return valve

7 Expansion valve

8 Boiler fill solenoid valve

9 Group body

10 Flowmeter

11 Steam valve

12 Hot water wand

13 Hot water solenoid valve

14 Boiler level probe

15 Safety valve

16 Anti vacuum valve

17 Injector

18 Solenoid valve group

19 Cold water mixing system solenoid valve

20 Drain hopper

21 Boiler drain valve

22 Pump pressure gauge

23 Boiler pressure gauge
