12 POINT I/O Field Potential Distributor Modules
Publication 1734-IN059D-EN-E - April 2013
Specifications
General Specifications
Attribute Value
Terminal base screw torque 0.8 Nm (7 lb-in.)
Module location Between I/O modules in 1734 system
Breaks power bus
Indicators None
POINTBus current Pass through
Power consumption None
Power dissipation None
Thermal dissipation None
Isolation voltage 250V (continuous), Basic Insulation Type
Type tested @ 2600V DC for 60 s, User power to system,
User power to Chassis ground.
Input voltage rating 12V DC, 24V DC nom
10...28.8V DC range
120V AC, 240V AC nom
Input current, max 10 A
Field power bus supply voltage 264V AC max,
12V DC, 24V DC, 10...28.8V DC range
120V AC, 240V AC @ 50/60 Hz
Field power bus supply current, max 10 A
Dimensions, HxWxD 76.2 x 25.4 x 133.4 mm
(3.00 x 1.00 x 5.25 in.)
Wiring category
(1)
(1)
Use this conductor category information for planning conductor routing as described in Industrial Automation Wiring
and Grounding Guidelines, publication 1770-IN041.
1 – on power ports
Wire size Determined by installed terminal block
Weight (approx.) 0.12 kg (0.27 lb)
Enclosure type rating None (open-style)
North American temp code T4A
IEC temperature code T4
