12 FLEX I/O Digital DC Output Modules
Publication 1794-IN094D-EN-P - July 2018
Total current draw through terminal base connection is limited to 10 A.
Separate power connections to each terminal base may be necessary.
Wiring Connections for 1794-OB32P
used with 1794-TB32 or 1794-TB32S Terminal Base Unit
Output Output Terminal Common Power
Output 0 A-0 Connect common to
terminals 36, 38, 40, and 42
Connect power to terminals
35, 37, 39, and 41
Output 1 A-1
Output 2 A-2
Output 3 A-3
Output 4 A-4
Output 5 A-5
Output 6 A-6
Output 7 A-7
Output 8 A-8
Output 9 A-9
Output 10 A-10
Output 11 A-11
Output 12 A-12
Output 13 A-13
Output 14 A-14
Output 15 A-15
Output 16 B-17 Connect common to
terminals 44, 46, 48, and 50
Connect power to terminals
43, 45, 47, and 49
Output 17 B-18
Output 18 B-19
Output 19 B-20
Output 20 B-21
Output 21 B-22
Output 22 B-23
Output 23 B-24
Output 24 B-25
Output 25 B-26
Output 26 B-27
Output 27 B-28
To Next Page
