B-14 M0 - M1 Files and G Files
Editing G File Data
Data in the G file must be edited according to your application and
the requirements of the specialty I/O module. You edit the data offline
under the I/O configuration function only. With the decimal and
hex/bcd formats, you edit data at the word level:
• G1:1 = 234 (decimal format)
G1:1 = 00EA (hex/bcd format)
With the binary format, you edit data at the bit level:
• G1/19 = 1
IMPORTANT
Word 0 of the G file is configured automatically
by the processor according to the particular
specialty I/O module. Word 0 cannot be
edited.
