4 Rockwell Automation Publication 46DFA-IN001A-EN-P - January 2019

PHOTOSWITCH DIN Rail Fiber Optic Amplifier

Figure 6 - Basic Settings (continued)

standard

indicaon

㸣 indicaon

Zero oﬀset

indicaon

Rotate Display

Received light level

indicaon

Besides the standard received light level indicaon,

the zero oﬀset indicaon and the % indicaon are available.

Select the Counter indicaon to enter the Counter mode

when it returns to Normal Operaon.

ECO mode

Used to reduce power consumpon.

Approx.15 seconds aer the seng, the 7-segment indicaon turns OFF.

Pressng any buon turns the display on and turns it oﬀ again aer 15 seconds.

Buon Operaon

Lock

Reset to Factory Default

Reset sensor sengs to factory default.

When the buon operaon lock is set, operaon of each buon is enabled aer the UP

buon is held down for approximately six seconds during normal operaon.

When approximately 10 seconds has elapsed without any buon operaon, the buon

operaon lock is set again.

Pin 2 Output Type Selecon.

Select PNP, NPN, or OFF (Output is disabled)

Counter Indicaon
