212 Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020
Chapter 4 Commissioning
Figure 194 - Converter Cabinet Components (3300/4160V)
Ground Bus
Isolated Gate Drive
Power Supplies
(IGDPS)
Inverter Modules
Rectifier Modules
Coolant Piping
