Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 267
Component Definition and Maintenance Chapter 5
Figure 222 - 18 Pulse Control and Cabling Cabinet (with LV Control Panel removed)
Motor Terminals
Transient
Suppression
Networks
Line Terminals
Current Transformers
Hall-Effect Sensor
Voltage Sensing
Hall-Effect Sensor
