Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 61
Drive Installation Chapter 2
Figure 50 - Control and Cabling Cabinet (18 Pulse version shown) (with Control Panel removed)
Current
Transformers
Voltage Sensing
Hall Effect Sensor
Hall Effect Sensor
Line Terminals
Transient
Suppression
Networks
Motor Terminals
