72 Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020
Chapter 2 Drive Installation
Figure 57 - Swing-out of Low Voltage Compartment
Latch
Key Interlock
Handle
Terminal Blocks -
Customer (TBC)
