2 PanelView Plus 7 Performance Terminals
Rockwell Automation Publication 2711P-PC007A-EN-P - March 2015
Hazardous Locations
The following information applies when operating this equipment in hazardous locations.
When marked, these products are suitable for use in "Class I, Division 2, Groups A, B, C, D"; Class I, Zone 2, Group IIC
hazardous locations and nonhazardous locations only. Each product is supplied with markings on the rating nameplate
indicating the hazardous location temperature code. When combining products within a system, the most adverse
temperature code (lowest "T" number) may be used to help determine the overall temperature code of the system.
Combinations of equipment in your system are subject to investigation by the local Authority Having Jurisdiction at the
time of installation.
Zones Dangereuses
Informations sur l’utilisation de cet équipement en environnements dangereux.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent qu'à une utilisation en environnements de Classe I Division
2 Groupes A, B, C, D dangereux et non dangereux. Chaque produit est livré avec des marquages sur sa plaque
d'identification qui indiquent le code de température pour les environnements dangereux. Lorsque plusieurs produits sont
combinés dans un système, le code de température le plus défavorable (code de température le plus faible) peut être
utilisé pour déterminer le code de température global du système. Les combinaisons d'équipements dans le système sont
sujettes à inspection par les autorités locales qualifiées au moment de l'installation.
Environment and Enclosure
USB Ports
This product contains USB host ports that comply with hazardous location environments. Field-wiring compliance
requirements are provided in compliance with National Electrical Code, Article 500.
The PanelView™ Plus 7 Performance terminals provide two separately-powered USB host ports. The table defines the
circuit parameters of these USB host ports.
The USB peripheral device and its associated cabling must have circuit parameters with the limits given in the previous
table for them to remain nonincendive when used with a PanelView Plus 7 Performance host port. If cable capacitance and
inductance are not known, use the following values from ANSI/ISA-RP 12.06.01-2003:
C
cable
= 197 pF/m (60 pF/ft)
L
cable
= 0.7 μH/m (0.20 μH/ft)
Nonincendive field wiring must be wired and separated in accordance with 501.10(B)(3) of the National Electrical Code
(NEC) ANSI/NFPA 70 or other local codes as applicable. This associated nonincendive field-wiring apparatus has not been
evaluated for use in combination with another associated nonincendive field-wiring apparatus.
Temperature Range
This equipment is certified for use within the ambient temperature range of 0…55 °C (32…131 °F), except
for the 19-in. terminal that must be 0…50 °C (32…122 °F). Do not use the equipment outside of these ranges.
Field/Power Wiring
Battery Removal
Perchlorate material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
This perchlorate warning only applies to primary Lithium Manganese Dioxide (LiMnO
2
) cells or batteries, and products
containing these cells or batteries, sold or distributed in California, USA.
WARNING: EXPLOSION HAZARD
• Do not disconnect equipment unless power has been removed or the area is known to be
nonhazardous.
• Do not disconnect connections to this equipment unless power has been removed or the area is
known to be nonhazardous. Secure any external connections that mate to this equipment by using
screws, sliding latches, threaded connectors, or other means provided with this product.
• Substitution of components may impair suitability for Class I, Division 2.
• Peripheral equipment must be suitable for the location in which it is used.
• The battery in this product must be changed only in an area known to be nonhazardous.
• All wiring must be in accordance with Class I, Division 2 wiring methods of Article 501 of the
National Electrical Code and/or in accordance with Section 18-1J2 of the Canadian Electrical Code,
and in accordance with the authority having jurisdiction.
AVERTISSEMENT : RISQUE D’EXPLOSION
• Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher
l'équipement.
• Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher les
connecteurs. Fixer tous les connecteurs externes reliés à cet équipement à l'aide de vis, loquets
coulissants, connecteurs filetés ou autres moyens fournis avec ce produit.
• La substitution de composants peut rendre cet équipement inadapté à une utilisation en
environnement de Classe I, Division 2.
• Les équipements périphériques doivent s'adapter à l'environnementdans lequel ils sont utilisés.
• S'assurer que l'environnement est classé non dangereux avant de changer la pile ou le module
horloge temps réel de ce produit.
• Tous les systèmes de câblage doivent être de Classe I, Division 2, conformément aux méthodes de
câblage indiquées dans les Articles 501 du National Electrical Code (Code Electrique National) et/ou
conformément à la Section 18-1J2 du Canadian Electrical Code (Code Electrique Canadien), et en
fonction de l'autorité de jurisdiction.
ATTENTION: Environment and Enclosure
This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II
applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6561 ft) without derating.
The terminals are intended for use with programmable logic controllers. Terminals that are AC powered must
be connected to the secondary of an isolating transformer.
This equipment is considered Group 1, Class A industrial equipment according to IEC CISPR 11. Without
appropriate precautions, there may be difficulties with electromagnetic compatibility in residential and other
environments due to conducted or radiated disturbances.
Korean Radio Wave Suitability Registration - When so marked this equipment is registered for
Electromagnetic Conformity Registration as business equipment (A), not home equipment. Sellers or users are
required to take caution in this regard.
이 기기는 업무용 (A 급 ) 전자파적합기기로서 판 매자 또는 사용자는 이 점을
주의하시기 바 라 며 , 가정외의 지역에서 사용하는 것을 목적으 로 합니다 .
This equipment is supplied as open-type equipment. It must be mounted within an enclosure that is suitably
designed for those specific environmental conditions that will be present and appropriately designed to
prevent personal injury resulting from accessibility to live parts. The interior of the enclosure must be
accessible only by the use of a tool. The terminals meet specified NEMA, UL type, and IEC ratings only when
mounted in a panel or enclosure with the equivalent rating. Subsequent sections of this publication may
contain additional information regarding specific enclosure type ratings that are required to comply with
certain product safety certifications.
In addition to this publication, see the following:
• Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1
, for additional installation
requirements.
• NEMA 250 and IEC 60529, as applicable, for explanations of the degrees of protection provided by different
types of enclosure.
Parameter Value Description
V
oc (USB)
5.25V DC Open circuit voltage of each host USB port.
The maximum applied voltage rating, V
max (peripheral)
, of the USB peripheral device
shall be greater than or equal to V
oc (USB)
.
V
max (peripheral)
≥ V
oc (USB)
, as appropriate.
I
sc (USB)
1.68 A Maximum output current of each host USB port.
The maximum current, I
max (peripheral)
, to which the USB peripheral device can be
subjected shall be greater than or equal to I
sc (USB).
I
max (peripheral)
≥ I
sc (USB)
C
a (USB)
10 μF This value is the maximum total capacitance that can be connected to a USB host port.
The total capacitance of the USB peripheral device and its associated cable must not
exceed the indicated value.
The maximum total capacitance, C
i (peripheral)
, and cable capacitance of the separate
USB peripheral device shall be less that or equal to C
a (USB)
.
C
i (peripheral)
+ C
cable(USB)
≤ C
a (USB)
L
a (USB)
15 μH This value is the maximum total inductance that can be connected to a USB host port.
The total inductance of the USB peripheral device and its associated cable must not
exceed the indicated value.
The maximum total inductance, L
i (peripheral)
, and cable inductance of the separate
USB peripheral device shall be less than or equal
to L
a (USB)
.
L
i (peripheral)
+ L
cable
≤ L
a (USB)
Input Voltage
(1)
(1) See label on product for power or current requirements.
Wiring Type Dual-wire Size Single-wire Size Strip Length Screw Torque
24V DC nom
(18…30V DC)
Stranded or solid
Cu 90 °C (194 °F)
0.3…1.3 mm
2
22…16 AWG
0.3…2.1 mm
2
22…14 AWG
7 mm (0.28 in.)
0.4…0.5 N•m
(3.5…4.4 lb•in)
100…240V AC
This product contains a lithium battery that may need to be replaced during the life of the product. For
instructions on the removal and replacement of the battery, see the PanelView Plus 7 Performance
Terminals User Manual, publication 2711P-UM008
. At the end of its life, the battery contained in this
product should be collected separately from any unsorted municipal waste. The collection and recycling
of batteries helps protect the environment and contributes to the conservation of natural resources as
valuable materials are recovered.
Associated Nonincendive
Field-wiring Apparatus
PanelView™ Plus 7 Performance Host
Product
USB Host Port
USB Peripheral Device
Nonincendive Field-wiring Apparatus
USB Host Port
USB Peripheral Device
To Next Page
