B-10 Accessories and Dimensions
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Figure B.5 PowerFlex 40 Flange Mount Cutout Dimensions – Dimensions are in
millimeters and (inches)
210
(8.27)
98
(3.86)
160
(6.30)
145
(5.71)
49
(1.93)
31
(1.22)
7.5
(0.30)
14
(0.55)
98.5
(3.88)
197
(7.76)
6.5
(0.26)
225
(8.86)
23.5
(0.93)
5.3
(0.21)
291.5
(11.48)
164
(6.46)
180
(7.09)
90
(3.54)
307.5
(12.11)
230.6
(9.08)
153.8
(6.06)
76.9
(3.03)
8
(0.31)
8
(0.31)
5.3
(0.21)
Frame B
Frame C
